90852 Anti-Collision Light

Product image 190852 Anti-Collision Light
Product image 290852 Anti-Collision Light
Product image 390852 Anti-Collision Light
Product image 490852 Anti-Collision Light
Product image 590852 Anti-Collision Light
Product image 690852 Anti-Collision Light
The Model 90852 Series is an FAA/TSO Approved self-contained LED anti-collision beacon. It's solid-state circuitry and LED light source allow for replacement of the legacy Whelen 90033 series halogen flashing beacons. Benefits include no moving parts, no EMI/RFI, no inrush current spikes and crisp on off cycles. There are several models available to provide compatibility with existing mounting patterns and profiles of the legacy beacons, thus eliminating the need to alter the aircraft.
Tech Specs
Model Part # Description Approvals
9085203 01-0790852-03 LED Anti-collision light 8 hole mount RED (Lower Mount) FAA TSO-C96a Class III
9085204 01-0790852-04 LED Anti-collision light 8 hole mount WHITE (Lower Mount) FAA TSO-C96a Class III
9085205 01-0790852-05 LED Anti-collision light 5 hole mount RED (Upper Mount) FAA TSO-C96a Class III
908525D 01-0790852-5D LED Anti-collision light 5 hole mount RED (Lower Mount) FAA TSO-C96a Class III
9085206 01-0790852-06 LED Anti-collision light 5 hole mount WHITE (Upper Mount) FAA TSO-C96a Class III
9085208 01-0790852-08 LED Anti-collision light 5.12" Diameter round mount WHITE (Lower Mount) FAA TSO-C96a Class III


Documents
Cross Reference Guide
90852 LED Part  # 90033 Legacy Part Number Beech Part Number Description Aircraft Model
01-0790852-03 01-0790033-03 101-360020-15 Anti-collision light 8 hole mount RED (Lower Mount) Beech King Air 300 SN: FA1 thru FA112; C90 SN: LJ-1138 and after
01-0790852-05 01-0790033-05 101-360020-17 Anti-collision light 5 hole mount RED (Upper Mount) Beech King Air; B200 SN: BB-1133, BB-1141, BB-1145 and After; B200C SN: BL-69 and After; B200GT SN:BY-1 and After; 300 SN: FA1 thru FA112; B300 SN: FL-1 and After; B300C SN: FM-1 and After; 1900 Airliner SN UB-62 and After * Also used on King Air 200 with Kit 101-3093 Installed
01-0790852-06 01-0790033-06 101-360020-19 Anti-collision light 5 hole mount WHITE (Upper Mount) Beech King Air; B200 SN: BB-1133, BB-1141, BB-1145, and After; B200C SN: BL-69 and After; B200GT SN: BY-1 and After; 300 SN:FA1 thru FA112; B300 SN: FL-1 and After; B300C SN: FM-1 and After; 1900 Airliner SN: UB-62 and After.
01-0790852-08
01-0790033-08
Grimes P/N: G7740A-19-24 Anti-collision light 5.12" Diameter round mount WHITE (Lower Mount) Beech King Air; F90 Serial - All, 200 Serial BB-2 thru BB-733 thru BB-735 thru BB-792 thru BB-794 thru BB-828 thru BB-830 thru BB-854 thru BB-1262 , 200C Serial BL-1 thru BL-112, BL-118 thru BL-126, B300 Serial FL-1 and After, B300C Serial FM-36 and After
